The electric clutch is operated by a switch located on the dashboard of the lawn mower.

John deere electric pto clutch adjustment.

John deere 316 318 420 pto clutch adapter mount plate he190. The pto is the mechanism that turns on the blades located under the mower deck. I attached some images from the manual. Electric clutches must be adjusted from time to time for optimal performance.

Why do i need to adjust the clutch. The pto function is what engages the mower blades of the lawn tractor. The mower s battery sparks the pto clutch which then guides the shaft and rotates the blades of the mower. The clutch has a pulley underneath it with a belt that goes back to the mower deck.

With a feeler gauge of between 013 015 for clutches used on 25 horsepower and under and 015 022 for clutches used on 25 31 horsepower tighten each nut down until slight contact is felt on the feeler gauge. If the gap becomes too large between the two contact plates it becomes difficult for the magnet to hold them together. Many lawn tractors particularly john deere riding mowers use a pto clutch. Make offer john deere pto clutch 316 318 322 330 332 420 430 lawn tractor rotor and pulley.

Lawn mower craftsman zts 7500. Electric clutch adjustment for outdoor power equipment. The pto works off of a 12 volt system. Most john deere lawn mowers are equipped with an electric pto power take off.

Chris first try to adjust the clutch. When the clutch is turned to the on position it engages a brake that turns the pulley allowing the blades to turn. If the wiring does not reveal any problem and a clutch adjustment does not resolve it it may be time to replace the clutch. Once all three are finished go back and check the air gap occasionally some minor adjustment will be required.

The electric clutch on a john deere lawn mower is responsible for the blades engaging on the mower deck.
